General Information：
• Grade:
C17200, C17000, C17300, C17500, C17510
RWMA Class2, RWMA Class 3, RWMA Class 4
W.-Nr 2.1247, 2.1248, 2.1285, 2.1258, 2.085, 2.1293
CW101C, CW102C, CW103C, CW104C, CW110C, CW106C
CuBe2, CuBe1.9, CuBe2Pb, CuCo1Ni1Be, CuCo2Be, CuNi2Be, CuCr1Zr
Copper-beryllium, leaded copper-beryllium, Copper-cobalt-beryllium,
Copper-nicke-beryllium, Copper-Chormium-Zirconium
• Diameter range: 0.3 - 12.0 mm
• Weight per coil: 5kgs - 80kgs
• Temper:
A (TB00), ¼ H(TD01), ½ H (TD02), ¾ H(TD03), H(TD04),
AT(TF00), ¼ HT(TH01), ½ H (TH02), ¾ H( TH03), HT(TH04)
or customize as client's requirements
• Standard:
ASTM B 197, AMS 4725, EN 12166
Mechanical and Electrical Properties：
Features of Copper Beryllium：
• Versatility in strength and durability
• Thermal conductivity
Typical Applications：
• Miniature machined electronic sockets
• Long travel coil springs
• Cold headed fasteners
• Spring loaded test probes
• Lightweight, fatigue resistant stranded cable
• Bandoliered connector contacts
• Braided shielding cloth
• Corrosion and biofouling resistant marine wire and wire mesh structures
• Eyeglass frames
Package：
Place of Origin： China
Certification： ISO ，ROHS
Model Number： C17300
Minimum Order Quantity： 30kg
Price： USD 30～50/KG
Packaging Details： Pack in coil+waterproofing winding film+Drier+Wooden Case
Delivery Time： 10～15 Working days
Payment Terms： L/C, T/T
Supply Ability： 50T/Month
Application
Our alloys combine a range of properties particularly suited to meet the exacting requirements of many applications in the automotive, electronic, aeronautical, Oil&Gas, watch, electro-chemical industries, etc. Beryllium Copper is widely used in those fields as contact springs in various applications like connectors, switches, relays, etc
Key Technology of Beryllium Copper(Heat treatment)
Heat treatment is the most important process for this alloy system. While all copper alloys are hardenable by cold working, beryllium copper is unique in being hardenable by a simple low temperature thermal treatment. It involves two basic steps. The first is called solution annealing and the second, precipitation or age hardening.
Solution Annealing
For the typical alloy CuBe1.9 (1.8- 2%) the alloy is heated between 720°C and 860°C. At this point the contained beryllium is essentially “dissolved” in the copper matrix (alpha phase). By rapidly quenching to room temperature this solid solution structure is retained. The material at this stage is very soft and ductile and can be readily cold worked by drawing, forming rolling, or cold heading. The solution annealing operation is part of the process at the mill and is not typically used by the customer. Temperature, time at temperature, quench rate, grain size, and hardness are all very critical parameters and are tightly controlled by ohmalloy.
Age Hardening
Age hardening significantly enhances the material’s strength. This reaction is generally carried out at temperatures between 260°C and 540°C depending on alloy and desired characteristics. This cycle causes the dissolved beryllium to precipitate as a beryllium rich (gamma) phase in the matrix and at the grain boundaries. It is the formation of this precipitate which causes the large increase in material strength. The level of mechanical properties attained is determined by the temperature and time at temperature. It should be recognized that beryllium copper has no room temperature aging characteristics.
Size Available
Main Market：North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Middle East, Africa, Oceania, Worldwide
Business Type ：Manufacturer, Exporter
Employees： 80~100
Annual Sales： 70-100 million 7000-1亿
Year Established： 2001
Export： 60% - 70%
