C17200 beryllium copper is a high-strength alloy material composed of copper and beryllium. It has excellent thermal conductivity, electrical conductivity, and corrosion resistance. The following is a comprehensive information introduction about C17200 beryllium copper.
Basic data:
-Chemical composition: Copper (Cu) -98.1%, Beryllium (Be) -1.9%
-Density: 8.36 g/cm ³
-Melting point: approximately 1030 ° C
-Thermal expansion coefficient: 17.7 × 10 ^ -6/° C
-Thermal conductivity: 315 W/m · K
-Conductivity: 45% IACS
-Tensile strength: 700 MPa
-Yield strength: 350 MPa
-Elongation rate: 15%
Performance characteristics:
1. High strength: C17200 beryllium copper has excellent tensile strength and yield strength, making it very suitable for applications that can withstand high and heavy loads.
2. Excellent thermal conductivity: C17200 beryllium copper has excellent thermal conductivity, which can quickly conduct heat, effectively reduce temperature, and prevent damage caused by overheating.
3. Excellent conductivity: Due to its high conductivity, C17200 beryllium copper is widely used in electrical and electronic devices such as connectors, wires, and soldering electrodes.
4. Corrosion resistance: The surface of C17200 beryllium copper can form a dense oxide layer, effectively resisting the erosion of most corrosive media, thereby extending the service life of the material.
5. Good machinability: Beryllium copper can obtain different properties and shapes through heat treatment and cold processing, which can meet the needs of different applications.
Application areas:
1. Electronic and electrical equipment: C17200 beryllium copper is widely used in the manufacture of electrical connectors, wires, relays, etc. Due to its high conductivity and corrosion resistance, it can ensure the reliable operation of equipment.
2. Molds and cutting tools: Beryllium copper has high hardness and excellent wear resistance, so it is commonly used in the manufacturing of molds, stamping dies, and cutting tools to provide longer service life and efficient processing performance.
3. Aerospace: C17200 beryllium copper is widely used in the aerospace industry to manufacture parts and components due to its high strength and corrosion resistance, which can meet extreme working conditions.
4. Automotive industry: Due to its high strength and wear resistance, C17200 beryllium copper is commonly used in automotive manufacturing to manufacture engine parts, braking systems, and transmission devices.
advantage:
1. High strength and excellent reliability, capable of withstanding heavy loads and high temperature environments.
2. Excellent thermal and electrical conductivity, capable of quickly conducting heat and current.
3. Excellent corrosion resistance, which can extend the service life of materials.
4. Good processability, the desired performance and shape can be obtained through different heat treatment and cold processing techniques.
Summary:
C17200 beryllium copper is an alloy material with high strength, high thermal conductivity, and corrosion resistance, widely used in fields such as electronics, electrical, aerospace, and automotive industries. Its excellent performance and processability make it an ideal material choice for many application fields.
